Introspect Technology, a JEDEC member and leading manufacturer of test and measurement instruments, has announced the M7030 DDR/LPDDR Protocol Analyzer. This instrument is designed for design validation and interoperability testing of next-generation memory interfaces, including LPDDR, DDR, GDDR, and HBM devices. It offers a native sampling rate of 80 GS/s per pin, the highest in the industry, making it suitable for future specifications such as LPDDR6 and DDR6.
Key Features and Benefits
The M7030 Protocol Analyzer enables rapid bring-up of memory devices, debugging of protocol timings, and long-term data integrity testing. It features training-free operation, automatically tracking all phases and voltage levels of a memory interface. The instrument is designed like an oscilloscope in the analog domain but functions as a high-channel-count, high-sampling-rate logic and protocol analyzer in the software domain.
Industry-Leading Sampling Rate
With a native sampling rate of 80 GS/s per pin, the M7030 can debug and diagnose the fastest memory links. This high sampling rate increases measurement confidence and future-proofs the equipment for upcoming memory standards.
Active Probing and Integrated-Tip Interposers
The M7030 uses active probe technology and integrated-tip interposers to handle unterminated signals in LPDDR5 and LPDDR6 memory interfaces, simplifying the probing process for engineers.
Handling Clock Stops and Instantaneous Clock Frequency Changes
The instrument's unique sampling architecture automatically deals with clock stops and instantaneous clock frequency changes, enabling testing under realistic system-level operating conditions rather than artificial fixed-frequency modes.
“The M7030 instrument is Introspect’s latest interpretation of the modern protocol analyzer, and we are thrilled to introduce it to our users worldwide,” said Dr. Mohamed Hafed, CEO at Introspect Technology. “Designed from the ground up by Introspect’s engineers working closely with their counterparts at leading memory and processor manufacturers, this product truly accentuates Introspect’s unique design philosophy, its remarkable tester architecture, and its legendary Pinetree software environment.”
Next-generation memory interfaces are being deployed across a wide range of system applications, creating challenges in design validation and interoperability testing due to more complex protocols, increasing data rates, and tight margins. The M7030 addresses these challenges by providing instant insight into live systems containing high-speed memory interfaces.
